InventorCAM 2021 SP4 HF1 for Autodesk Inventor 2018-2022 (x64)
File Size: 4.74 GB
InventorCAM - the CAD/CAM system of new generation developed by Israeli firm SolidCAM Ltd (the Official distributor in Russia - Consistent Software). This system is a comprehensive solution for the automation of metalworking production. Using a wide range of strategies offered by InventorCAM for turning, milling, turning-milling and electrical discharge machining, a technologist can quickly prepare the necessary set of control programs for machining a product.
Functionality of InventorCAM
Support for 64bit computing due to the presence of a special version for 64bit
2.5-axis milling
InventorCAM provides high efficiency and accuracy of 2.5-axis milling of parts. Various processing strategies are supported for such elements as a contour, a selection (with islands) and a groove, as well as various types of hole processing: drilling, countersinking, threading, etc. The system has a wide range of possibilities for 2.5-coordinate processing of analytical surfaces.
3-axis milling
InventorCAM provides a wide range of tools that can be effectively applied to the processing of products with complex geometries (dies, molds) and prismatic parts. The geometry for 3D machining is a 3D surface or solid model. The system supports various types of roughing and finishing strategies, such as raster processing with a specified or automatically determined raster angle, equidistant processing, projection processing, waterline processing, etc.
In addition to the already listed possibilities of 2.5- and 3-axis processing, InventorCAM offers tools for identifying and refining areas that were not processed in previous transitions. It is possible to create a database of typical technological processes. Once created, such a parametrized technological process can be repeatedly used in the future, which significantly reduces the production preparation time, increases the reliability of the developed programs, unifies the style of technological development, guarantees the use of only optimal processing technologies and ensures the independence of production from the human factor. The absence of overcuts is guaranteed by the presence of means of control and visualization of machining.
Multi-Axis Machining
InventorCAM offers various tools for creating multi-axis part programs on 4- and 5-axis machining centers. The model is installed in a user-defined processing plane, after which the system automatically calculates all the necessary displacement and rotation parameters for the part zero. As a result, the preparatory-final transition time is significantly reduced and the processing accuracy is increased.
Turning and turning-milling
InventorCAM has a wide range of functions for automating the creation of part programs for turning and turning-milling. InventorCAM supports various types of tools, which allows you to efficiently perform longitudinal turning, facing, grooving, etc. In addition, InventorCAM allows you to automatically rough and finish complex contours. Rotary tool support allows you to perform milling and drilling transitions on machining centers.
EDM
The set of wire EDM strategies offered by InventorCAM allows you to machine external and internal contours with a constant and variable angle of inclination. The possibility of 4-axis processing is provided. A special algorithm prevents the processed material from falling. InventorCAM gives the user control over the physical processing parameters along the entire wire path.
Chinese Simplified, Chinese Traditional, Czech, Danish, Dutch, English, French, German,Hebrew, Hungarian, Italian, Japanese,Korean, Polish, Portuguese, Russian, Spanish, Turkish Tablet : Present (
TeAM SolidSQUAD-SSQ)
System Requirements
Autodesk Inventor 2021 (and below) pre-installed 64bit only
